You can put together the new EickView HD video endoscope system according to your wishes and needs.
EickView HD video processor
The EickView HD video processor is the basis of your endoscope system. The powerful LED light source enables optimal illumination in any position. Various settings on the video processor allow you to adapt the image quality to your needs and requirements. The new HbE mode also enables an improved display of vessels. Still images can be saved directly on the EickView HD video processor on a USB storage medium. The image data can also be transferred to an existing PC.
EickView HD video endoscopes
The EickView HD video endoscopes deliver even more brilliant images thanks to the further improved video chips while maintaining the same size. The main areas of application for the EickView HD video endoscopes are bronchoscopy and gastroscopy. The wide range of available endoscope sizes means you can carry out examinations on everything from small animals to horses. The scope of delivery of the endoscopes includes a pressure tester, 2 cleaning brushes, a cleaning set and a transport case.
Technical data of endoscopes:
- Direction of view: 0°
- Resolution: 1,000,000 pixels
- Distal end contains 1 CMOS camera chip, 2 light guides, working channel, lens rinsing nozzle
- Scope of delivery: EickView video endoscope, pressure tester, 2 cleaning brushes, cleaning set, transport case
EickView PRO HD Upgrade
With the EickView PRO HD Upgrade, you can turn the video processor into a very mobile endoscopy unit, giving you access to other endoscopic disciplines such as arthroscopy, rhinoscopy, otoscopy, etc. The Windows 10 tablet with a high-contrast 12.3 inch PixelSense display (2,736 x 1,824 pixels) with a battery life of up to 13 hours serves both as a display and for storing still images and video recordings. Further benefits of the upgrade include even easier-to-use video software as well as a mouse and keyboard (optional) for easy patient and image management.
